Five separate Borrelia spirochete bodies follow distinct loose, irregular wave paths with varied lengths, axes, amplitudes, and three to six broad undulations.
Morphology reconstruction Editorially reviewed

Representative Borrelia spirochete geometry, shown as five separate bodies with broad, irregular waves. This genus-level reconstruction is non-diagnostic and is not a micrograph.

WikiBiome / Microbiome MedicineTaxonomy-, morphology-, and control-handoff-informed reconstruction
Scientific media record1 verified identifier
Subject
Borreliataxon · genus
Review
Editorial review completeIdentifiers authority-verified · Accessibility validated · · borrelia|borrelia-morphology-v1.webp
Digital source
Trained-algorithmic mediaCreated with a trained generative algorithm and reviewed by WikiBiome for subject identity, scientific framing, identifiers, provenance, and accessibility.
License
CC BY-SA 4.0Created

A genus of spirochete bacteria transmitted by Ixodes ticks, best known as the causative agent of Lyme disease—the most common tick-borne illness in the Northern Hemisphere.

Borrelia burgdorferi sensu lato comprises approximately 20 genospecies, with B. burgdorferi sensu stricto (North America), B. afzelii, and B. garinii (Europe and Asia) causing most human infections.

What makes Borrelia genuinely extraordinary from a metallomics perspective is that it has completely eliminated iron from its biology—a radical evolutionary strategy that simultaneously evades host Nutritional Immunity (Metal Sequestration), prevents Fenton Chemistry, and creates a unique manganese-dependent vulnerability.

Evidence map4 cited passagesInspect provenance +
01
The Iron-Free Strategy

Borrelia burgdorferi does not accumulate iron and lacks iron-dependent enzymes (, quasi-experimental). This is not merely iron tolerance—it is a wholesale elimination of one of biology's most fundamental transition metal cofactors. The evolutionary logic is elegant:

02
Manganese: The Sole Metal Shield

Having abandoned iron, Borrelia has built its entire antioxidant defense on manganese. EPR (electron paramagnetic resonance) and ENDOR spectroscopy reveal two complementary Mn-based antioxidant systems operating in living cells (, quasi-experimental):

03
Manganese Toxicity: The Self-Poisoning Vulnerability

A critical finding: in metabolite-depleted stationary phase cells, manganese supplementation becomes toxic (, quasi-experimental). When metabolite pools are exhausted, excess Mn2+ cannot form protective H-Mn complexes and instead causes off-target binding—a form of manganese-mediated mis metallation that damages non-Mn enzymes. This metabolite-dependent M

04
Key Studies

(quasi-experimental)—Uses EPR/ENDOR spectroscopy to directly observe Mn speciation in living B. burgdorferi cells; discovers dual MnSOD/H-Mn antioxidant system; demonstrates Mn toxicity under metabolite depletion; establishes Borrelia as a natural experiment in iron-free biology.

Contents1. Metal Dependencies2. Key Enzymes and Virulence Factors3. Ecological Role4. Conditions Associated5. Key Studies6. Cross-References

Metal Dependencies#

The Iron-Free Strategy#

Borrelia burgdorferi does not accumulate Iron and lacks iron-dependent enzymes (,[1]Londono 2025 — EPR Spectroscopy Reveals Antioxidant Manganese Defenses in the Lyme Disease Pathogen Borrelia burgdorferiAndres F Londono, Ajay Sharma, Venkatesan Kathiresan et al. · 2025Open reference 1 quasi-experimental). This is not merely iron tolerance—it is a wholesale elimination of one of biology's most fundamental transition metal cofactors. The evolutionary logic is elegant:

  1. Fenton chemistry avoided—Without intracellular iron, iron(II) (Fe2+) + H2O2 reactions cannot generate hydroxyl radicals, eliminating the most common source of oxidative self-damage
  2. Nutritional immunity circumvented—Host iron-sequestering proteins (transferrin, lactoferrin, lipocalin-2) are irrelevant to an organism that does not need iron
  3. Iron-based antimicrobial strategies neutralized—The host cannot starve Borrelia of a metal it does not require

Manganese: The Sole Metal Shield#

Having abandoned iron, Borrelia has built its entire antioxidant defense on Manganese. EPR (electron paramagnetic resonance) and ENDOR spectroscopy reveal two complementary manganese (Mn)-based antioxidant systems operating in living cells (,[1]Londono 2025 — EPR Spectroscopy Reveals Antioxidant Manganese Defenses in the Lyme Disease Pathogen Borrelia burgdorferiAndres F Londono, Ajay Sharma, Venkatesan Kathiresan et al. · 2025Open reference 1 quasi-experimental):

manganese PoolEPR SignatureIdentityFunctionLocation
L-manganeseBroad, featurelessMnSOD (enzyme-bound)Catalytic O2-- dismutationCell surface
H-manganeseNarrow, 6-peakMn2+-metabolite complexesNon-enzymatic O2-- scavengingCytoplasm

MnSOD at the cell surface provides the primary antioxidant defense against extracellular superoxide (from the host Oxidative Stress burst). H-manganese complexes (manganese bound to phosphate, carboxylates, amino acids, and peptides) provide cytoplasmic protection against intracellular superoxide.

The H-Mn Deficit#

Borrelia has very low H-manganese (Mn) content—approximately 10% of total manganese as H-manganese complexes, compared to >90% in radiation-resistant organisms like Deinococcus radiodurans. This explains Borrelia's radiosensitivity despite manganese accumulation: it relies predominantly on enzymatic (MnSOD) rather than non-enzymatic (H-manganese) antioxidant protection.

Manganese Toxicity: The Self-Poisoning Vulnerability#

A critical finding: in metabolite-depleted stationary phase cells, manganese supplementation becomes toxic (,[1]Londono 2025 — EPR Spectroscopy Reveals Antioxidant Manganese Defenses in the Lyme Disease Pathogen Borrelia burgdorferiAndres F Londono, Ajay Sharma, Venkatesan Kathiresan et al. · 2025Open reference 1 quasi-experimental). When metabolite pools are exhausted, excess manganese(II) (Mn2+) cannot form protective H-manganese complexes and instead causes off-target binding—a form of manganese-mediated Mis-Metallation that damages non-manganese enzymes.

This metabolite-dependent manganese toxicity represents a potential therapeutic vulnerability: conditions that deplete Borrelia's metabolite buffering capacity could convert its own manganese accumulation into an autotoxic weapon.

Key Enzymes and Virulence Factors#

SystemMetalFunction
MnSOD (SodA)ManganeseSurface-localized superoxide dismutase; primary antioxidant
H-manganese (Mn) complexesManganeseNon-enzymatic cytoplasmic antioxidant
Outer surface proteins (OspA, OspC)NoneTick attachment, immune evasion, tissue tropism
Flagellar motorMotility through viscous connective tissue
Complement evasion (CRASPs)Factor H recruitment to evade complement lysis

Ecological Role#

Borrelia is an obligate pathogen maintained in a tick-mammal transmission cycle. It does not colonize the human Gut Microbiome and has no commensal niche.

Its ecological strategy is one of extreme metabolic minimalism: a very small genome (approximately 1.5 Mb), limited biosynthetic capacity, and dependence on the host for most nutrients.

The iron-free biology is part of this minimalist strategy—rather than investing in complex iron acquisition systems, Borrelia simply abandoned iron dependency entirely.

Comparison with Other Metal Strategies#

OrganismIron Usemanganese (Mn) UseAntioxidant StrategyRadioresistance
B. burgdorferiNoneHigh (90% L-manganese)MnSOD dominantLow
D. radioduransLowVery high (>90% H-manganese)H-manganese complexes dominantVery high
E. coliHighLow (90% L-manganese)iron (Fe)-SOD + catalaseLow
L. plantarumLowHigh (>90% H-manganese)H-manganese complexesHigh

Conditions Associated#

Lyme disease—Multi-system infection with early (erythema migrans, flu-like illness) and late (arthritis, carditis, neurological) manifestations. Neuroborreliosis—CNS infection causing meningitis, radiculopathy, and cranial neuropathy. Lyme arthritis—Inflammatory arthritis of large joints, particularly the knee.

Post-treatment Lyme disease syndrome—Persistent symptoms after antibiotic treatment; mechanism debated.

Key Studies#

  • [1]Londono 2025 — EPR Spectroscopy Reveals Antioxidant Manganese Defenses in the Lyme Disease Pathogen Borrelia burgdorferiAndres F Londono, Ajay Sharma, Venkatesan Kathiresan et al. · 2025Open reference 1 (quasi-experimental)—Uses EPR/ENDOR spectroscopy to directly observe manganese (Mn) speciation in living B. burgdorferi cells; discovers dual MnSOD/H-manganese antioxidant system; demonstrates manganese toxicity under metabolite depletion; establishes Borrelia as a natural experiment in iron-free biology.

Cross-References#

  • Manganese—Sole transition metal cofactor; MnSOD and H-manganese (Mn) complexes as dual defense
  • Iron—Completely eliminated from Borrelia biology; evolutionary anti-Fenton strategy
  • Mis-Metallation—manganese toxicity under metabolite depletion represents manganese-mediated mis-metallation
  • Superoxide Dismutase—MnSOD as primary antioxidant at cell surface
  • oxidative stress—Host respiratory burst countered by manganese-based defenses
  • Nutritional Immunity (Metal Sequestration)—Iron restriction irrelevant to iron-free organism; manganese restriction as alternative host strategy
  • Fenton Chemistry—Eliminated by removing intracellular iron
Generated evidence record

References 9

Numbered by first appearance in the article, then reconciled with its declared source list.

  1. 1

    Andres F Londono, Ajay Sharma, Venkatesan Kathiresan et al. (2025). Londono 2025 — EPR Spectroscopy Reveals Antioxidant Manganese Defenses in the Lyme Disease Pathogen Borrelia burgdorferi. mBio.

  2. 2

    Monisha Jaishankar, Tenzin Tseten, Naresh Anbalagan et al. (2014). Toxicity, Mechanism and Health Effects of Some Heavy Metals. Interdisciplinary Toxicology.

  3. 3

    Prakash Lingasamy, Vijayachitra Modhukur, Reet Mändar et al. (2024). Lingasamy 2024 — Exploring Immunome and Microbiome Interplay in Reproductive Health. Seminars in Reproductive Medicine.

  4. 4

    L. Bazzichi, V. Giorgi, M. Di Franco et al. (2024). Bazzichi 2024 — Environmental Factors and Fibromyalgia Syndrome (Review). Clinical and Experimental Rheumatology.

  5. 5

    Cristina Sarasa-Buisan, Jesus A G Ochoa de Alda, Cristina Velazquez-Suarez et al. (2024). Sarasa-Buisan 2024 — An Ancient Bacterial Zinc Acquisition System Identified from a Cyanobacterial Exoproteome. PLOS Biology.

  6. 6

    Imran M, Das KR, Naik MM (2019). Co-selection of multi-antibiotic resistance in bacterial pathogens in metal and microplastic contaminated environments: an emerging health threat. Chemosphere.

  7. 7

    Zufa Sabeel, Zhao Yang (2025). Microbiome-Targeted Nanoplatforms and Engineering Approaches in Breast Cancer Therapy. Molecular Cancer.

  8. 8

    Joy R Paterson, Joshua M Wadsworth, Rebecca J Lee et al. (2025). Paterson 2025 — Enhanced Resistance of Metal Sequestering Agents by Reconfiguration of the Staphylococcus aureus Cell Wall. npj Antimicrobials and Resistance.

  9. 9

    Weider T, Genoni A, Broccolo F et al. (2022). Weider et al. 2022 — High Prevalence of Common Human Viruses in Thyroid Tissue. Frontiers in Endocrinology.
